Specifications

Insulator Material: Glass filled polyester, type PBT,
94 V O, UL Rated.
Contact Material: Phosphor Bronze Alloy
Contact Plating:
Current Rating: 3 amp at 30°C
Contact Resistance:
-
Gold and/or Tin over .000050” Nickel,
(See Contact Plating Options).
Contact to Daughter Card:
10 m
Insulation Resistance: 5000 M
Dielectric Withstand Voltage: 1000 V AC
Daughter Board Insertion Force:
16 oz max. per contact pair
when tested with a .071” thick gage.




Daughter Board Withdrawal Force:
1 oz min. per contact pair
when tested with a .054” thick gage.

Features

• Extra large chamfered entry
• Conforms to Bell-core spec TR-TSY-00078
• Extended card scoops available
• Replaceable contacts
• Molded in polarization available between
contact, or on contact position.
• De-population of contacts per
customer specification.
• Available in selective gold plate at contact point
• Many other custom options available, including,
but not limited to:
• Single or Both Ends Open
