Specifications

Current Rating: 0.3 Amps
Insulator Resistance: 100 Megohms min
Contact Resistance: 40m ohm max
Dielectric Withstanding: AC 250V
Operating Temperature: -40° ~± 85° C
Contact Material: Phosphor Bronze
Insulator Material: High Temperature
Thermoplastic. UL 94V-0
Actuator: LCP, UL 94V-0
